OUT1 |
DC Voltage |
12V-16V |
| Rated current (three-phase 380V input) | 356A | |
|
Ripple & Noise |
<1% |
|
| Source adjustment rate |
<1% |
|
|
Load Regulation |
<1% |
|
| Start-up and rise time |
<20S |
|
| Power-off retention time |
>5mS |
|
|
OUT2 |
DC Voltage |
12.3V |
| Rated current (three-phase 380V input) |
21A |
|
|
Ripple & Noise |
<1% |
|
|
Voltage Accuracy |
12.2V-12.4V |
|
| Source adjustment rate |
<1% |
|
|
Load Regulation |
<1% |
|
| Start-up and rise time |
<20S |
|
| Power-off retention time |
>10mS |
|
|
Input |
Voltage Range |
380-415V AC |
|
Frequency Range |
50/60Hz |
|
|
Power Factor |
>0.99(full load) |
|
|
Leakage Current |
<3.5mA（380V 50/60Hz） |
|
|
Protection |
Input undervoltage protection value |
320-340V AC |
|
Output Short Circuit |
Yes |
|
| Over-temperature protection |
Yes |
|
| Output overcurrent protection value |
380A-460A |
|
|
（protection value varies under different voltage） |
||
|
Environment |
Operating Temperature |
20-50℃ |
|
Operating Humidity |
20%-90%RH（non-condensing） |
|
|
Altitude |
< 2000m |
|
|
Structure |
Dimensions |
319.6mm*290mm*80mm |
|
Net Weight |
6.4Kg |
|
| Cooling method | Immersion Cooling | |
| Noise |
/ |
